P/N
CA-1K8-00M1WN-00
LA SERIE
Serie V
MODELO
V200 TG
???????????????
(2020 Version)
V200 TG
TIPO DE CAJA
Middle tower
DIMENSIONES (AL X AN X PR)
446 x 204 x 439 mm
(17.6 x 8.3 x 17.3 inch)
???????????????
(2020 Version)
447 x 217 x 432 mm
(17.6 x 8.54 x 17 inch)
PESO NETO
6.5 kg / 14.33 lb
???????????????
(2020 Version)
6.06 kg / 13.36 lb
PANEL LATERAL
4mm Tempered Glass x 1
COLOR
Exterior & Interior : Black
MATERIAL
SPCC
SISTEMA DE REFRIGERACI�N
Rear (exhaust) :
120 x 120 x 25 mm fan (1000rpm- 16dBA)
BAH�AS DE EXPANSI�N
3 x 2.5�
2 x 3.5�
???????????????
(2020 Version)
2 x 3.5� or 2 x 2.5�
2 x 2.5�
RANURAS DE EXPANSI�N
7
PLACAS BASE
6.7� x 6.7� (Mini ITX)- 9.6� x 9.6� (Micro ATX)- 12� x 9.6� (ATX)
PUERTOS E/S
USB 3.0 x 1- USB 2.0 x 2- HD Audio x 1- R Button x 1
FUENTE DE ALIMENTACI�N
Standard PS2 PSU (optional)
COMPATIBILIDAD VENTILADORES
Front:
3 x 120mm- 2 x 140mm
Top:
2 x 120mm- 2 x 140mm
Rear:
1 x 120mm
COMPATIBILIDAD RADIADORES
Front: 1 x 240mm- 1 x 280mm
Rear: 1 x 120mm
???????????????
(2020 Version)
Front: 1 x 360mm- 1 x 280mm
Top: 1 x 240mm-
Rear: 1 x 120mm
LIMITACIONES
CPU cooler height limitation: 160mm
VGA length limitation: 380mm
PSU length limitation: 170mm
???????????????
(2020 Version)
CPU cooler height limitation: 160mm
VGA length limitation: 320mm
PSU length limitation:
160mm (With HDD Rack)
200mm (Without HDD Rack)
